HDCAM WiFi High Definition Microscope Camera
The Fein Optic HDCAM WiFi microscope camera emits its own WiFi signal allowing for up to 6 devices to connect to the signal. The camera has a back illuminated color sensor, allowing light to easily be asborbed in the active layer on the sensor, which results in greater quantum efficiency. This WiFi camera has 5mp image capture to SD card or your smart device. The HDMI output provides a fast connection to HDMI monitor for crisp image viewing.
| Image Sensor | 1/1.8″ Sony Exmor IMX183(C) (6.22 x 4.67) CMOS |
| Pixel Size | 2.4 x 2.4µm |
| Resolution | 2592 x 1944 (5 Megapixels) |
| Frame Rate | WiFi: 25fps @ 1920 x 1080 |
| HDMI: 30fps @ 1920 x 1080 | |
| Binning | 1×1 |
| Exposure | 0.03ms~918ms |
| Output | WiFi, HDMI |
| Power | DC12V/2A, power on/off switch. |
| App / HDMI Controls | USB Mouse for on-screen control with HDMI only. |
| Image Capture to SD Card, or in App Software. | |
| White Balance, Auto White Balance. | |
| Perform calibration and measurements. | |
| App Software Features | Image capture and motion video. |
| Adjustment of white balance, color, frame rate, exposure, gain, flip, sampling, bit depth, ROI, histogram, darkfield correction. | |
| Annotation | |
| Measurement and Calibration: angles, lines, diameter, polygon, etc. | |
| Operating System for Software (WiFi) | App on Windows/Linux/OSX/Android Platform. |
| Maximum Connected Devices | 3-6 devices (depending on environment and connection distance). |
| Operating Temp | -10~50°C |
| Storage Temp | -20~60°C |
| Operating Humidity | 30-80%RH |
| Storage Humidity | 10-60%RH |
| Size | 78mm (3.07″) W x 77mm (2.76″) D x 92mm (3.62″) H, 1lb. |
| Connection | C-Mount Threads |
