Image Sensor |
1/1.8″ Sony IMX678(C) (7.68 x 4.32) |
Pixel Size |
2.0 x 2.0µm |
Resolution |
3840 x 2160 (8 Megapixels) |
Frame Rate |
HDMI: 60fps @ 3840 x 2160 4K Resolution |
Binning |
1×1 |
Exposure |
0.19ms~1000ms |
Output |
HDMI, USB3, GE (Gigabit Ethernet) |
Power |
DC12V/2A, power on/off switch. |
HDMI Controls |
USB Mouse for on-screen control. |
8 Megapixel Image Capture to SD Card or USB flash drive, Video recording 72fps to SD Card or USB flash drive. |
Camera control panel: Exposure, Gain, White Balance, Color, Sharpness. |
Toolbar: Zoom, Mirror, Comparison, Freeze, Crossline, On-Monitor Measuring. |
USB Controls. |
White Balance, Auto White Balance, ROI White Balance. |
Capture still images or motion video with software. |
USB works with full use of software on PC or Laptop. Will not work with MAC. |
Software Features |
High speed video streaming via Gigabit Ethernet (GE). |
Image capture, still or motion video. |
Adjustment of white balance, color, frame rate, exposure, gain, flip, sampling, ROI, histogram, darkfield correction. |
Annotation |
Measurement and Calibration: angles, lines, diameter, polygon, etc. (PC only) |
Operating System for Software (USB) |
Windows 7, 8, 10, 11 (32 & 64 bit), Linux |
PC Requirements (USB) |
CPU equal or greater than Intel Core2 2.8GHz |
Memory: 4GB or more |
USB3.0 Port, Disply of 19″ or larger, 4K resolution. |
Operating Temp |
-10~50°C |
Storage Temp |
-20~60°C |
Operating Humidity |
30-80%RH |
Storage Humidity |
10-60%RH |
Size |
3.87″ W x 2.46″ D x 3.07″ H, 1lb. |
Monitor |
Not included, but works best with a 4K monitor. |
Connection |
C-Mount Threads |
